| Product Number | 6232-M-J20AA Bearing |
| Bore diameter(d) | 160 mm |
| Bore diameter(d) | 160 mm |
| Bore diameter(d) | 160 mm |
| Bore diameter(d) | 160 mm |
| Outside diameter(D) | 340 mm |
| Outside diameter(D) | 340 mm |
| Outside diameter(D) | 290 mm |
| Outside diameter(D) | 290 mm |
| Width(B) | 68 mm |
| Width(B) | 68 mm |
| Width(B) | 48 mm |
| Width(B) | 48 mm |
| Basic dynamic load rating(Cr) | 300.000 N |
| Basic dynamic load rating(Cr) | 300.000 N |
| Basic dynamic load rating(Cr) | 212.000 N |
| Basic dynamic load rating(Cr) | 212.000 N |
| Basic static load rating(Cor) | 320.000 N |
| Basic static load rating(Cor) | 320.000 N |
| Basic static load rating(Cor) | 203.000 N |
| Basic static load rating(Cor) | 203.000 N |
| Limiting speed(nG) | 3.400 1/min |
| Limiting speed(nG) | 3.400 1/min |
| Limiting speed(nG) | 4.050 1/min |
| Limiting speed(nG) | 4.050 1/min |
| Reference speed(nϑr) | 2.800 1/min |
| Reference speed(nϑr) | 2.800 1/min |
| Reference speed(nϑr) | 3.100 1/min |
| Reference speed(nϑr) | 3.100 1/min |
| Weight(mass) | 31,25 kg |
| Weight(mass) | 31,25 kg |
| Weight(mass) | 14,44 kg |
| Weight(mass) | 14,44 kg |
| Cage | M |
| Cage | M |
| Cage | M |
| Cage | M |
| Lubricant | without |
| Lubricant | without |
| Lubricant | without |
| Lubricant | without |
| Radial internal clearance | CN |
| Radial internal clearance | CN |
| Radial internal clearance | CN |
| Radial internal clearance | CN |
| Coating | J20AA |
| Coating | J20AA |
| Coating | J20AA |
| Coating | J20AA |
| da | 174 mm |
| da | 177 mm |
| da | 177 mm |
| da | 174 mm |
| Da | 276 mm |
| Da | 323 mm |
| Da | 323 mm |
| Da | 276 mm |
| Ra | 3 mm |
| Ra | 3 mm |
| Ra | 2,5 mm |
6232-M-J20AA Bearing|Insulated deep groove ball bearings|deep groove ball bearings|Insulated bearing|current insulation bearing| 6232.M.J20AA bearing
