| Product Number | 6338-M-J20C Bearing |
| Bore diameter(d) | 200 mm |
| Outside diameter(D) | 360 mm |
| Width(B) | 58 mm |
| Basic dynamic load rating(Cr) | 270.000 N |
| Basic static load rating(Cor) | 310.000 N |
| Limiting speed(nG) | 3.200 1/min |
| Reference speed(nϑr) | 2.430 1/min |
| Weight(mass) | 27 kg |
| Cage | M |
| Lubricant | without |
| Radial internal clearance | CN |
| Coating | J20C |
| da | 217 mm |
| Da | 343 mm |
6338-M-J20C Bearing|Insulated deep groove ball bearings|deep groove ball bearings|Insulated bearing|current insulation bearing| 6338.M.J20C bearing
