| Product Number | CSG/CSF-32 Bearing |
| d | 26 |
| d3 | |
| D | 112 |
| H | 22.5 |
| C | 21.5 |
| C1 | |
| T | |
| B | 19 |
| B1 | |
| H2 | 3 |
| D1 | 90 |
| D2 | 64 |
| d1 | 74 |
| d2 | 68.6 |
| Dm | |
| dm | 104 |
| 外安装孔尺寸1 | 16-Φ4.5 |
| 外安装孔尺寸2 | |
| 中安装孔尺寸 | |
| dn | 55 |
| 内安装孔尺寸1 | 8-M10 |
| 中安装孔尺寸 | |
| 中安装孔尺寸 | |
| dL | 40 |
| 内安装孔尺寸2 | 8-M10 |
| rmin | |
| rmin(内) | |
| rmin(外） | |
| Dwp | |
| Z-Dw | |
| Cr(kN) | 12.5 |
| Cor(kN) | 35.6 |
| Kg | 0.9 |
| 对应减速机型号 | CSG/CSF-23 机型 |
| Fw | |
| Ew | |
| Bc | |
| Rsmin | |
| RV减速器型号 | |
| GB轴承型号 | |
| 最大径向变形量 | |
| 输入转速 | |
| 输出力矩 | |
| 谐波减速器型号 |
CSG/CSF-32 Bearing|Precision Cross Bearing|Special Bearings For Robot Harmonic Reducers | CSD seriesCSG/CSF-32_Bearing
