| Product Number | 32048-X-XL-J20AA Bearing |
| Bore diameter(d) | 240 mm |
| Outside diameter(D) | 360 mm |
| Width(B) | 76 mm |
| Cage | Standard |
| Basic dynamic load rating(Cr) | 1.060.000 N |
| Basic static load rating(Cor) | 1.680.000 N |
| Limiting speed(nG) | 2.150 1/min |
| da min | 261 mm |
| Da max | 346 mm |
| ra max | 4 mm |
| Weight(mass) | 26,2 kg |
| d1 | 298,5 mm |
| Reference speed(nϑr) | 1.060 1/min |
| Tmin | -30 °C |
| Tmax | 200 °C |
