| Product Number | NU218-E-XL-M1-F1-J20AA Bearing |
| Bore diameter(d) | 100 mm |
| Outside diameter(D) | 150 mm |
| Width(B) | 24 mm |
| Cage | M1 |
| Basic dynamic load rating(Cr) | 116.000 N |
| Basic static load rating(Cor) | 135.000 N |
| Radial internal clearance | C3 |
| Limiting speed(nG) | 9.000 1/min |
| da min | 106 mm |
| Da max | 143 mm |
| ra max | 1,5 mm |
| Weight(mass) | 1,387 kg |
| rmin | 1,5 mm |
| D1 | 132,9 mm |
| Reference speed(nϑr) | 4.150 1/min |
| Tmin | -30 °C |
| Tmax | 150 °C |
NU218-E-XL-M1-F1-J20AA Bearing|Insulated Cylindrical roller bearings|Cylindrical roller bearings|Insulated bearing|current insulation bearing|NU218.E.XL.M1.F1.J20AA Bearing
