BestQuality single row angular contact ball bearings Factory

Double row angular contact ball bearingsThe design of the double row angular contact ball bearing corresponds to two single row angular contact ball bearings arranged back to back. The bearing is capable of carrying high radial loads and thrust loads in both direction. It is particularly suitable for applications calling for high axial rigidity.Double Row Angular Contact ball bearings may offer some economic benefits as well as handling and mounting benefits versus pairs of Single Row Angular Contact ball bearings; however, they may offer less design flexibility and performance in some cases.Design Attributes * Specific geometry of angular contact bearing raceways and shoulders creates ball contact angles that support higher axial loads. * Expanded options include special lubricants, cage materials, preloads and coatings for additional corrosion resistance. Double Row Angular Contact ball bearings are available in two numerical series:?5200 Series – Lighter load, higher speed, more/smaller balls per bore diameter.?5300 Series – Heavier load, slower speed, fewer/larger balls per bore diameter.If you need help in selecting the best products for your particular application, please remember that design engineering and application assistance are available from LOTTON as part of our value-added services designed to make your job easier.

Four-point contact ball bearings are radial single row angular contact ball bearings with raceways that are designed to support axial loads in both directions. For a given axial load, a limited radial load can also be supported (Load ratio). The bearings are separable, comprise solid outer rings, split inner rings and ball and cage assemblies with brass or polyamide cages. The two-piece inner rings enable a large complement of balls to be accommodated. The inner ring halves are matched to the particular bearing and must not be interchanged with those of other bearings of the same size. The outer ring with the ball and cage assembly can be mounted separately from the two inner ring halves.Four-point contact bearings are single-row angular contact ball bearings and therefore require significantly less space in an axial direction than double-row designs.In conclusion, these advantages improve the overall cost-efficiency of the bearing position significantly and thus bring about a sustainable increase in the efficiency of the machine and equipment.Wuxi LOTTON Bearing Manufacturing Co., Ltd. China four-point contact ball bearings manufacturers-Wuxi LOTTON Bearing Manufacturing Co., Ltd.,Main products include various ball bearings, roller bearings

Thrust ball bearings are separable bearings. Thrust ball bearings, composed of bearing balls supported in a ring, can be used in low thrust applications where there is little axial load.The thrust ball bearings are classified into two kinds: unidirectional thrust bearing and bidirectional thrust bearing. The former can bear the axial force in one direction and the latter can bear he axial forces in two directions. Both unidirectional and bidirectional thrust ball bearings cannot bear any radial force. Thrust ball bearing can limit axial displacement of shafts or housings in one or two direction, but not radial displacement. Therefore, the bearings are usally used with deep groove ball bearings.

Wuxi LOTTON Bearing Manufacturing Co., Ltd. Customized Stainless steel bearings manufacturers From China,With German and Japanese engineers, all of our production uses high technology and continuously improves quality. And we have high-precision production equipment to produce bearings that can replace world-renowned brand bearings to meet the huge needs of customers.Specs•AISI 304 stainless steel ball bearings have much greater corrosion resistance than those made of SAE 52100 bearing steel or AISI 440C stainless steel•Heat resistant grease is used in AISI 304 and AISI 440C stainless steel ball bearings•AISI 440C stainless steel bearings have a high resistance to corrosion and chemicals, plus high stability in high temperaturesApplications:•Agricultural•Food Processing•Gearbox & Industrial Clutch•Health care•Material Handling•Packaging Machinery•Pump & Compressor•RoboticsStainless steel bearings provide a several notable benefits when other materials pose problems. Notably, stainless steel offers greater chemical and corrosion resistance, along with better stability in high temperature environments. These benefits make stainless steel bearings a great fit for applications in demanding environments or specialty circumstances.Stainless steel deep groove ball bearings are corrosion resistant when exposed to moisture and several other media. They are available capped (with seals or shields) or open. Open bearings that are also available capped may have recesses in the ring side faces.These bearings have a lower load carrying capacity than same-sized bearings made of high chromium steel.Stainless Steel Pillow Block Bearings not only have the characteristics of the ordinary bearings: Low vibration, low noise, high precision rotating, lower friction torque and high speed running but also have its special usage function.The range of application is wide: It is an acid-proof and alkali-proofIt can work in corrosion medium such as sea water, river aqua, distilled water, sparse nitric acid, maritime climate, steam and so onIt can work in the high or low temperature environmentCommon usage for Stainless Steel Pillow Block include: Agriculture, Automotive, Pump, Sporting and Consumer Goods, Construction, Manufacturing Equipment, Conveyor and Fan Assemblies,Farm Machinery, HVAC, Feed Mill, Economical housed bearing solution and many other Industrial Equipment.Main model: UCP , UCFL , UCF , UC

Ceramic bearings with two types: Ceramic Hybrid Bearings and Full Ceramic BearingsCeramic bearings are available in variety of sizes and styles: Deep groove ball bearings, Angular contact bearings,Self aligning ball bearing, Insert bearings.

High temperature bearings and bearing units are designed to deliver increased reliability, reduced complexity and decreased environmental impact in operating temperatures up to 350 °C (660 °F), making these products very suitable for applications in kiln trucks, roller hearth furnaces, and bakeries.

Originally designed for car wheel applications, hub bearing units are greased-for-life, compact units providing defined and pre-adjusted clearance or preload, plus an integrated sealing solution. Also referred to as hub assembly, wheel hub unit

Single row deep groove ball bearings are the most widely used bearing type. The raceway grooves on both the inner and outer rings have circular arcs of slightly larger radius than that of the balls. In addition to radial loads, axial loads can be imposed in either direction. Because of their low torque, they are highly suitable for applications requiring high speed and low power loss.They are available capped (with seals or shields) or open. Open bearings that are also available capped may have recesses in the ring side faces.With steel shields, non-contact or friction rubber seals installed on one or both sides and are pre-lubricated with grease. These bearings can be supplied filled with different types of grease and with different filling levels depending on the customer requirements.The large production series allows their relatively low price.Wuxi LOTTON Bearing Manufacturing Co., Ltd. Wholesale single row deep groove ball bearings bearing ball deep groove withgoodprice-Wuxi LOTTON Bearing Manufacturing Co., Ltd.
